Product Descriptions

The TMP102 device is a digital temperature sensor ideal for NTC/PTC thermistor replacement where high accuracy is required. The device offers

an accuracy of ±0.5°C without requiring calibration or external component signal conditioning. Device temperature sensors are highly linear

and do not require complex calculations or lookup tables to derive the temperature. The on-chip 12-bit ADC offers resolutions down to 0.0625°C.

The 1.6-mm × 1.6-mm SOT563 package is 68% smaller footprint than an SOT-23 package. The TMP102 device features SMBus?, two-wire and

I2C interface compatibility, and allows up to four devices on one bus. The device also features an SMBus alert function. The device is specified

to operate over supply voltages from 1.4 to 3.6 V with the maximum quiescent current of 10 μA over the full operating range.

The TMP102 device is ideal for extended temperature measurement in a variety of communication, computer, consumer, environmental

industrial, and instrumentation applications. The device is specified for operation over a temperature range of –40°C to 125°C.

The TMP102 production units are 100% tested against sensors that are NIST-traceable and are verified with equipment that are NIST-traceable

through ISO/IEC 17025 accredited calibrations.

Product Features

? SOT563 Package (1.6-mm × 1.6-mm) is a 68% Smaller Footprint than SOT-23

? Accuracy Without Calibration:

– 2.0°C (max) from –25°C to 85°C

– 3.0°C (max) from –40°C to 125°C

? Low Quiescent Current:

– 10-μA Active (max)

– 1-μA Shutdown (max)

? Supply Range: 1.4 to 3.6 V

? Resolution: 12 Bits

? Digital Output: SMBus, Two-Wire, and I 2C Interface Compatibility

? NIST Traceable

Product Applications

? Portable and Battery-Powered Applications

? Power-supply Temperature Monitoring

? Computer Peripheral Thermal Protection

? Notebook Computers

? Battery Management

? Office Machines

? Thermostat Controls

? Electromechanical Device Temperatures

? General Temperature Measurements:

– Industrial Controls

– Test Equipment

– Medical Instrumentations
